LV-07 SMT surface mount component rework station with intelligent touchscreen and three temperature zones

LV-07 BGA Rework Station Core Features
1.Independent 3-Temperature Zone Control： Upper/lower hot air zones + IR preheating zone, ±2℃ temperature accuracy. Supports 8-section temperature setting, simultaneous top/bottom heating, and independent control of each zone. Avoids PCB deformation via uniform heating, with 4 temperature curve displays, data storage, and external temperature calibration.
2.Precise Optical Alignment： HD split-screen CCD color vision system with zoom, auto-focus, aberration correction, and brightness adjustment. Equipped with 15” LCD monitor for clear observation.
3.User-Friendly Operation： HD touch screen interface, integrated heating device and mounting head. 360° rotatable titanium alloy nozzles (easy to replace). X/Y/R axes micrometer fine-tuning, ±0.01mm alignment accuracy.
4.Versatile & High-Performance： 4 operating modes (remove/weld/mount/semi-auto). Adjustable air speed, synchronized saving of fan speed and temperature curves. Slide rail-driven upper heating head for higher precision.
